Description
Monster Overview:
Tackle corrosive or outdoor builds with M4-1.75 Torx®/6-Lobe Pan Head 45° Plastite® / Plas-Fix Thread-Rolling • Thread-Forming Screws from Monster Bolts. The 45° trilobular profile cold-flows thermoplastic bosses, creating chip-free, vibration-resistant threads. A factory wax coat on passivated A2 stainless slashes seating torque for faster, smoother assembly.
Monster Features
- 45° Thread-Rolling Design: Plastite/Plas-Fix geometry, 1.75 mm pitch, high pull-out strength.
- A2 / 18-8 Stainless: Long-term corrosion resistance for medical, food-grade, and outdoor use.
- Low Seating Torque: Wax lubrication + trilobular lobes cut drive effort and boss stress.
- Drive: Internal Torx® (6-lobe star) T20 — high torque transfer with zero cam-out.
- Full Thread: Fully threaded shank grips plastics of any thickness.
Monster Specifications
| Feature | Details |
|---|---|
| Diameter / Pitch | M4 × 1.75 mm (Plastite 45°) |
| Available Lengths | Fully threaded — select length above |
| Head / Drive | Pan Head / T20 Torx® (6-lobe) |
| Thread Form | 45° trilobular thread-rolling / thread-forming |
| Material | A2 / 18-8 Stainless Steel |
| Finish | Passivated & Wax-Lubricated (RoHS) |
| System of Measurement | Metric |
| Standards / Reference | Plastite® 45 design guidelines (Ref.) |
More Monster Bolts
Need other Plastite sizes or materials? Explore our complete range of Metric Plastite-Style Screws.
