Bulk M5 Hex-Socket Flat Head DIN 7500 M (Type Z) Thread-Forming Screws – A2 Stainless – Monster Bolts


Length: 2000 Qty - M5-0.8 x 10mm
Price:
Sale price$157.95

Description

Bulk M5 DIN 7500M Hex-Socket Flat-Head Thread-Forming Screws – A2 Stainless – Monster Bolts

Monster Overview:

Remove the tapping step and keep production on schedule with M5-0.8 DIN 7500 M Type Z Flat-Head Hex-Socket Thread-Forming Screws in A2 / 18-8 stainless steel. Their lobular 7500 M groove cold-forms true 6g ISO-metric threads in aluminum, mild steel, brass and other ductile metals—delivering chip-free, vibration-resistant joints that remain fully serviceable.

Monster Features

  • Countersunk Flat Head 90°: Flush seating for hinges, trim and precision panels.
  • Hex-Socket Drive: Internal Allen 3 mm A/F keeps hardware snag-free and tamper-resistant.
  • DIN 7500 M Lobular Thread: Rolls—not cuts—metal for higher strip-out & fatigue resistance.
  • A2 Stainless Steel: Rust-proof 18-8 alloy—no plating to crack or flake.
  • Passivated + Factory Wax: Bright contamination-free finish and controlled-torque lubrication (RoHS).
  • Full Thread: Continuous engagement for sheets, extrusions or castings of any thickness.
  • Bulk Master Cartons: OEM-volume quantities at industrial-grade pricing.

Monster Specifications

Feature Details
Diameter / Pitch M5 × 0.8 mm
Available Lengths 8 mm – 35 mm (fully threaded)
Head / Drive Flat Countersunk 90° / Hex Socket 3 mm
Standard DIN 7500 M (Type Z)
Material A2 / 18-8 Stainless Steel
Finish Passivated & Wax-Lubricated (RoHS)
System of Measurement Metric

Applications

Ideal for aluminum extrusion frames, kiosks, robotics chassis, solar hardware, and any sheet-metal assembly where tapping adds time and cost.

Order Yours Today and Experience the Monster Bolts Difference!

Buy with confidence—every bulk carton ships fast from the USA and is backed by our commitment to quality, responsive support, and industrial-grade savings.
